Glazed Framed Ledged Doors

Glazed framed ledged doors can be made with one large pane, four, six or nine panes. These panes are individual units (not one pane of glass with bars planted on the front).

All our doors are bespoke, made to measure from sustainable highest quality kiln dried solid wood and are of mortice and tenon construction, glued and wedged. All external doors are supplied with wooden weatherboards. Lots of other styles and woods are available see below.

Please Note: The number of T & G Boards may vary depending on the sizes of your door and the timber we have in stock at the time. If you require a specific number of boards there may be a small charge.

About Us

Contact Us

Door Styles

Frame Styles

Door Furniture
and Accessories

Glazing

Finish Options

Windows

Workshop

F.A.Q.

Email

9 Pane Glazed Framed Ledged Door and Frame
Frame Sizes: 915mm wide x 1965mm high - Glass: Clear - Ironmongery: Wrought Iron
Finish: Osmo 429 UV Protection Oil Tints - Natural

bespoke front doors french grey gfl9-2



European Oak 6 Pane Glazed Framed Ledged Door and Frame with Arched Header Ref. GFL6-5
Frame Sizes: 1245mm wide x 2120mm high
Lock: Winkhaus secured by design – 3 point multilock system Ironmongery: Wrought Iron
Glass: Clear - Factory Spray Stained: Medium Oak

european oak 6 pane door with arched header bespoke

Utile (painted) 9 Pane Over 1 Raised and Fielded Panel Bow Fronted Door and Sapele (painted) Frame - GFL9-PAN
Frame Sizes: 975mm wide x 1910mm high
Glass: Chantilly Small Diamond Lead - Ironmongery: Wrought Iron (From The Anvil)
Factory Spray Painted: RAL 9001 Cream

Utile (painted) 4 Pane Glazed Framed Ledged Door and Sapele (painted) Frame with Fully Glazed Sidelights - GFL4-4
Frame Sizes: 1210mm wide x 1930mm high - Door Width: 812mm
Glass: Sandblast (clear border to door) - Ironmongery: Pewter
Factory Spray Painted: RAL 7030 Stone Grey

European Oak 4 Pane Framed Ledged Door and Frame with Matching 8 Pane Side Panel - GFL4-3
Frame Sizes: 2215mm wide x 245mm high - Door Width: 822mm
Glass: Clear - Ironmongery: Wrought Iron (From The Anvil)
Factory Spray Stain: NE03 Teak Basecoat, Medium Oak Basecoat

Idigbo (painted) 4 Pane Over 2 Raised and Fielded Panel Door and Frame (Ovolo Scribe) - GFL4-PAN2
Frame Sizes: 915mm wide x 2060mm high
Glass: Clear - Ironmongery: Wrought Iron (From The Anvil)
Factory Spray Painted: F&B No.30 Hague Blue

European Oak 6 Pane Glazed Framed Ledged Door and Frame
Frame Sizes: 880mm wide x 2100mm high
Lock: Winkhaus secured by design – 3 point multilock system Ironmongery: Polished Chrome
Glass: Clear - Factory Spray Stained: Clear Basecoat, Cypruss Topcoat

cottage style door and frame

Hardwood (painted) 4 Pane Over 2 Raised and Fielded Panel Door and Frame
Frame Sizes: 880mm wide x 1650mm high
Lock: Winkhaus secured by design – 3 point multilock system Ironmongery: Wrought Iron (From The Anvil)
Glass: Clear - Factory Spray Painted: F&B No.88 Lamp Room Grey

Hardwood (painted) 6 Pane Glazed Framed Ledged Door and Frame
Frame Sizes: 885mm wide x 2105mm high
Lock: Winkhaus secured by design – 3 point multilock system Ironmongery: Wrought Iron (From The Anvil)
Glass: Clear - Factory Spray Painted: F&B No.298 Bancha

cottage style door and frame

Iroko (painted) 6 Pane Glazed Framed Ledged Door and Frame
Frame Sizes: 925mm wide x 2085mm high
Lock: 5 lever sashlock & deadlock - Ironmongery: Supplied by customer
Glass: Clear - Factory Spray Painted: White

glazed framed ledged door and frame

European Oak 6 Pane Glazed Framed Ledged Door and Frame
Frame Sizes: 1120mm wide x 2090mm high
Lock: Winkhaus secured by design – 3 point multilock system Ironmongery: Wrought Iron
Glass: Clear - Stain: Medium Oak

Painted 9 Pane Glazed Framed Ledged Door and Frame
Frame Sizes: 925mm wide x 2010mm high
Lock: Winkhaus secured by design – 3 point multilock system Ironmongery: Wrought Iron
Colour: F&B Shade 234 Vert De Terre

Iroko 4 Pane Glazed Framed Ledged Door and Frame with Matching Part Glazed Sidelight
Frame Sizes: 1480mm wide x 2060mm high - door width: 838mm
Stain ref. NE08 - Glass: Clear

iroko 4 pane door

Painted 4 Pane Glazed Framed Ledged Door and Frame
Frame Sizes: 895mm wide x 2020mm high
Lock: Euro sashlock - Ironmongery Satin Chrome: Euro handles ref. DL30Y - Letterplate: M36E
Colour: F&B Shade 275 Purbeck Stone - Glass: Clear

painted four pane door

Hardwood 6 Pane Glazed Framed Ledged Door and Frame with direct glazed side window
Overall Frame Sizes: 1800mm wide x 2035mm high - Door frame sizes: 1170mm w x 2035mm h - Window sizes: 630mm w x 1025mm h
Lock: Winkhaus secured by design – 3 point multilock system Ironmongery: Polished Chrome - Glass: Clear
Colour: F&B Shade 17 Lichen

lichen front door

European Oak 9 Pane Glazed Framed Ledged Door and Frame
Frame Sizes: 935mm wide x 2110mm high
Lock: Winkhaus Heritage ‘Secured by Design’self locking multilock system
Ironmongery: From the Anvil Pewter - external cylinder pull, letter plate and centre door knob

Iroko 6 pane Glazed Framed Ledged Door and Frame
More information about this doorset

iroko door and frame

European Oak Two Pane Glazed Framed Ledged Door and Frame with Matching Sidelight
Frame Sizes: 1520mm wide x 2130mm high - Door Width: 914mm
More information about this doorset

oak glazed framed ledged doorset

European Oak Two Pane Glazed Framed Ledged Door and Frame with Matching Sidelight
Frame Sizes: 1340mm wide x 2080mm high - Door Width: 914mm
More information about this doorset

oak 2 pane glazed framed ledged door and frame with sidelight

European Oak 6 Pane Glazed Framed Ledged Door and Frame
Frame sizes: 914mm x 2057mm
Locks: 5 lever mortice sashlock and 5 lever mortice deadlock
Ironmongery: Kirkpatrick lever handles, letterplate and bell push

oak door glazed framed ledged

European Oak 9 Pane (1 pane of glass with plant on glazing bars) Glazed Framed Ledged Door
and Hardwood (Painted) Frame with 10 Pane Glazed Sidelights
Frame Sizes: 1910mm wide x 2025mm high - Door Width: approx. 866mm

Lock: Winkhaus Heritage nightlatch ‘Secured by Design’ self locking multilock system
Ironmongery: Brass external cylinder pull and letterplate ref. M36D

oak door with painted sidelights

Glazed Framed Ledged door with 2 panes across and 3 panes down and
frame with Sidelight -Solid Hardwood factory spray painted- 2-3GFL-2
Frame Sizes: 1280mm wide x 2200mm high Door Width: 838mm
Lock: 3 point Winkhaus secured by design' multilock system
Kirkpatrick euro handles and Kirkpatrick letterplate ref. 1963

glazed framed ledged door and sidelight

Glazed Framed Ledged door with 2 panes across and 3 panes down and
frame with matching side windows - Solid Hardwood factory spray painted- 2-3GFL
Lock: 5 lever mortice sashlock, lever lock handles ref. 2440 - Kirkpatrick wrought iron
Overall Frame Sizes: 1580mm wide x 1920mm high Door Frame Sizes: 930mm wide x 1920mm high
Window Sizes: 325mm wide x 1200mm high

glazed framed ledged door

9 Pane Glazed Framed Ledged Door and Frame - Solid Hardwood factory spray painted
Lock: 3 point Winkhaus secured by design' multilock system
Frame Sizes: 1030mm wide x 2100mm high

 cottage style 9 pane framed ledged door

European Oak Six Pane Glazed Framed Ledged Door and Frame
Frame Sizes this example: 975mm x 2060mm - any other sizes available
Ironmongery Kirkpatrick
Letterplate Postal Knocker ref. 1085 - Euro Lever Handles ref. 2462

oak door 6 glazed panes

European Oak Six Pane Glazed Framed Ledged Door
and frame shaped header

oak door glazed framed ledged

bespoke oak doors



GLAZED FRAMED LEDGED DOORSET PRICES (Doors and Frames)
Door 56mm thick double boarded and insulated pre-hung with locks and handles, full factory sprayed (stained or painted)

Click here or on the picture for DOORSET prices

arts and crafts door brochure

PDF file - if you are unable to open PDF's please ask us to send in a different format


single door prices

DOORS OVER 3FT WIDE P.O.A.

Six Pane Glazed Framed Ledged Door and Frame with Split Glazed Sidelights
Lock: 3 point winkhaus 'secured by design' multilock system - Kirkpatrick wrought iron euro lever door handles ref. 2462
Frame Sizes: 1370mm x 1985mm

oak door 6 pane split sidelights

Painted six Pane Glazed Framed Ledged Doors

painted 6 pane glazed framed ledged door glazed framed ledged door gfl10

oak glazed framed ledged door

oak door 4 pane fl

oak half lead glazed framed ledged door with side window

oak door half glazed fl lead
PLEASE NOTE!
Glass / Door Proportions
Our doors are glazed from the outside this is the traditional way for wooden doors. If you would like your door to be
glazed from the inside please state at time of order. Doors with single vision panels are glazed from the inside

Door only prices include 14mm clear Planitherm toughened double glazed units. Door and frame prices include 24mm Planitherm toughened double glazed units with warm edge spacer bars - Click here to see patterns etc.

The pictures above are typical examples of glazed framed ledged doors. Our experienced joiners will work out the best proportions from
the door sizes you give us. If you have a specific requirement please ask.
These pictures are for illustration only glass content may vary depending on your door sizes

All glazed units are individual pieces i.e. 6 pane stable door has 6 panes not one pane with bars planted on the front.

Boarding
As all our doors are made to your specific sizes the number of T & G Boards may vary from the examples in the
website. If you require a specific number there may be a small charge please ask.
